RECTANGULAR FUEL TANK 24 1/2" DIAMETER 62" LENGTH 120 GALLONS DRIVER SIDE REAR FILL FOR KENWORTH

- Fuel Tank
- Made Of 11 Gauge Aluminum
- Dimensions:
- Diameter - 24.5 Inches
- Length Seam To Seam - 62 Inches
- Length Over All - 64 Inches
- Gallons U.S. - 120
- Driver Side Rear Fill
- Filler Neck Rear Fill
- 7.50 Inches From Rear Weld Seam
- 15.00 Inches Above Horizontal Weld Seam - Back Of Tank
- Manifold With Sending Unit Hole
- 32.00 Inches From Rear Weld Seam
- 5.00 Inches Above Horizontal Weld Seam - Back Of Tank
- Vent Opening
- 26.00 Inches From Rear Weld Seam
- 10.00 Inches Above Horizontal Weld Seam - Back Of Tank
- Drains Or Cross Overs
- 7.50 Inches From Rear Weld Seam
- Caps And Fittings Sold Separately
- Welded Seams To Prevent Leakage
- CNC Laser Technology For Precision Cuts
- DOT Compliant
- Sold Individually
- Warranty On Fuel Tank Against Defects In Workmanship & Material From Date Of Purchase

* - Please Verify Manifold Style, Dimensions, Filler And Fittings For Sizes And Locations Before Purchasing Fuel Tanks, There May Be More Than One Option For Your Year, Make And Model **

***High Quality Aftermarket Replacement Part (Not OEM)

* - Replaces OE Number Ft0205206


-Warranty: 2 Years
