FUEL TANK 19 1/2" X 19 1/2" X 37 3/4" 52 GALLONS PASSENGER SIDE REAR FILL FOR HINO

- Fuel Tank
- 11 Gauge Aluminum
- Dimensions:
- 19.50 Inch Height
- 19.50 Inch Depth
- 35.75 Inch Length Seam To Seam
- 37.75 Inch Length Over All
- 52 Gallons
- Filler Neck - Rear Fill
- 5.75 Inch From Rear Weld Seam
- Sending Unit Hole
- 24.25 Inch From Rear Weld Seam
- 5.50 Inch From Front Side
- Vent Hole
- 0.50 Inch NPT
- 20.875 Inch From Rear Weld Seam
- 8.00 Inch From Front Side
- Pickup Port -
- 17.50 Inch From Rear Weld Seam
- 8.00 Inch From Front Side
- Return Ports -
- 14.25 Inch From Front Weld Seam
- 10.00 Inch Below Horizontal Weld Seam
- Caps And Fittings Sold Separately
- Has Provisions For Mounting Steps
- Welded Seams To Prevent Leakage
- CNC Laser Technology For Precision Cuts
- DOT Compliant
- Sold Individually
- Warranty On Fuel Tanks Against Defects In Workmanship & Material From Date Of Purchase

* - Please Verify Manifold Style, Dimensions, Filler And Fittings For Sizes And Locations Before Purchasing Fuel Tanks, There May Be More Than One Option For Your Year, Make And Model **

***High Quality Aftermarket Replacement Part (Not OEM)

- Replaces Oe Number 77100-4601A

* - This Tank Is Not Equipped With A Built-In Draw Tube ***


-Warranty: 2 Years
