FUEL TANK 23" DIAMETER 60" LENGTH 100 GALLONS CENTERED FILL FOR PETERBILT 2006 - POST

- Fuel Tank
- Made Of 11 Gauge Aluminum
- Dimensions:
- 23 Inch Diameter
- 55 Inch Length Seam To Seam
- 60 Inch Overall Length
- 100 Gallons
- Filler Neck- Center Fill
- 30.00 Inches From Rear Weld Seam
- 16.50 Inches Above Horizontal Weld Seam
- Original Style Manifold With Sending Unit Hole
- 30.00 Inches From Rear Weld Seam
- 11.50 Inches Above Horizontal Weld Seam
- Pickup And Return Ports - Tubes Built In To Tank
- 27.50 Inches From Rear Weld Seam
- 20.25 Inches Below Horizontal Weld Seam
- Drains Or Cross Overs
- 27.50 Inches From Rear Weld Seam
- 24.50 Inches Below Horizontal Weld Seam
- Caps And Fittings Sold Separately
- Welded Seams To Prevent Leakage
- CNC Laser Technology For Precision Cuts
- DOT Compliant
- Sold Individually
- Warranty On Fuel Tank Against Defects In Workmanship & Material From Date Of Purchase

* - Please Verify Manifold Style, Dimensions, Filler And Fittings For Sizes And Locations Before Purchasing Fuel Tanks, There May Be More Than One Option For Your Year, Make And Model **

- Aftermarket Replacement Part (Not OEM) ***


-Warranty: 2 Years
